Part #: WEM BF8VS9-13H
This Weldmark Blue Ghost Flame welding helmet is necessary for personal protection when operating a UV curing system or drying products with ultraviolet irradiation.
Features:
- 3 year lens replacement warranty
- 3 months headgear and helmet warranty
- Lightweight 18 ounce high impact resistant nylon shell
- High quality lens performance (DIN 1/2/1/2)
- 3.86″ x 1.73″ viewing area
- Auto darkening
- 1/25,000 darkening time
- Internal 9-13 variable shade adjustment
- Internal sensitivity and delay dial adjustments
- Grind mode
- 5 Amp TIG rating
- Auto on/off
- Replacement AAA (2) batteries
- Solar powered
- Large 2/3 replacement sweatband
- Magnifying (cheater) lens compatible
- 5 point adjustment headgear
- ANSI Z87.1-2003 / CSA Z94.3, CE/DIN approved
Specifications:
- Optical class: 1 / 2 / 1 / 2
- Viewing area: 98x44mm (3.86″x1.73″)
- Cartridge size: 110x90x9mm (4.33″x3.54″x0.35″)
- Arc sensor: 2
- Light state: DIN 3.5
- Shade: DIN 9 ~ 13
- Shade control: Internal, variable shade
- Power on/off: Fully automatic
- Sensitivity control: Adjustable by dial knob
- UV/IR protection: Up to Shade DIN16 at all times
- Power supply: Solar cell. Battery change required, 2 x AAA Alkaline batteries
- Low battery warning: Red light
- Switching time: 1/25,000 s. from light to dark
- Delay (dark to light): 0.1 ~ 1.0s by dial control knob
- Low amperage TIG rated: greater than or the same as 5 amps
- Grinding: Yes
- Operating temperature: -10 degrees C ~ 55 degrees C (14 degrees F ~ 131 degrees F)
- Storing temperature: -20 degrees C ~ 70 degrees C (-4 degrees F ~ 158 degrees F)
- Helmet material: High impact resistant nylon
- Total weight: 450g
- Application range: MIG; MAG/CO2; SMAW; Air carbon cutting; TIG (excellent lower amperage TIG response); PLASMA arc welding/cutting
- Approved: ANSI Z87.1-2003 / CSA Z94.3, CE / DIN
